260357 Bulk Fiber Optic Cable, Breakout Style, Multimode, 62.5/125 Plenum Applications OFNP / FT6

    Bulk Fiber Optic Cable
Click image to enlarge
Base Price:
Call for Price
Catalog No: 260357
Model No: 260357 Breakout Plenum
Micron Size:62.5/125
Strands:12
Product Type:Bulk Cable
Length, Ft.:Any
Fiber Mode:Multimode
Fiber Size:62.5/125

UPS

Shipping Terms

Shipments are made via UPS Ground, unless otherwise specified. Freight charges are prepaid and added to your invoice. We can estimate the freight costs for you.

We can ship freight collect on your account, just provide your UPS Account Number.

We can also ship via the carrier of your choice. Provide the details and your account number.

Products shall be shipped F.O.B. Electro Standards' facility. Title to and risk of loss or damage to the products shall pass to you upon Electro Standards delivery of the products to a carrier for shipment. Title to software will remain with the applicable licensor. Electro Standards' prices do not include shipping and handling charges. Electro Standards reserves the right to use its own discretion in the manner and routing of shipments. Electro Standards shall be permitted to deliver products in separate lots.

Shipping Return Policy

  • To return an item, contact Electro Standards at 401-943-1164 to obtain a Return Material Authorization (RMA) number. RMA numbers are valid for 30 days after the date of the shipment and cannot be extended or re-issued. We are unable to accept returns without an RMA number.
  • All returns except those of defective product are subject to a 15% restocking fee, and additional charges for handling or freight are refunded only in cases of defective products.
  • Return freight must be shipped prepaid. We recommend that you insure the package as you are responsible for risk of loss on all returned packages. We recommend that all cartons are properly packed as Electro Standards is not responsible for product damaged en route. We do not issue call tags for product returns.
  • Returned product must be clean, undamaged, and complete with all manuals, accessories, documents and packaging. The items must be in a resalable condition.
  • The product must have with it a copy of the original invoice or packing slip and the appropriate RMA paperwork.
  • If your item is not working properly, please contact Electro Standards at 401-943-1164 for help in trouble-shooting your application.
  • If the product is defective, Electro Standards will repair or replace that item (at our discretion) upon receipt and evaluation of the original product.
  • Electro Standards reserves the right to authorize product returns after 30 days from the invoice date in some cases. If the product is accepted after 30 days, credit will be issued toward future pruchases only and some additional restocking charges may be applied.
  • All credits from RMAs must be used within one calendar year of issue.

Ask a Question

Protected Document Request



Overview

Bulk Fiber Optic Cable (Breakout Style) Multimode, 62.5/125 µm

260357 Custom Lengths, Plenum Applications (OFNP/FT6)

Features:

  • Breakout design enables individual routing of fibers for termination and maintenance.
  • Tight Buffered, simplex cords are stranded around a central member and encased in a flexible jacket.
  • Multimode 62.5/125 micron fiber.

Specifications:

  • Buffer Diameter: 900 µm
  • Fiber Type: 62.5 µm core, 125 µm cladding
  • Maximum Attenuation: 3.75 dB/km @ 850 nm, 1.5 dB/km @1300 nm.
  • Minimum Bandwidth: 160 Hz-km @ 850 nm, 500 Hz @1300 nm.

Bulk Fiber Optic Cable (Breakout Style) is designed for voice, data, video, and imaging transmissions.

With breakout style of fanout style cables, the strands are packaged individually or in groups. This enables you to divide cables to serve user with individual strand lines and eliminates the need for patch panels.

All ESL products are available for export.
