Control and Monitor the Model 7271 A/B/C/D Switch Remotely via ASCII Commands

November 30, 2011

For Immediate Release

Model 7271 Single Channel RJ45 A/B/C/D Switch with Serial Remote Control Port


Electro Standards Laboratories, Cranston, RI, announces the Model 7271 single channel RJ45 A/B/C/D switch with serial remote control port. The Model 7271 allows the user the capability of sharing a single port interface device connected to the COMMON port among four other devices connected to the A, B, C and D ports.



The Model 7271 may be controlled locally via a front-panel push-button or remotely from the DB9 remote control port located on the rear panel. The DB9 remote port provides control through RS232 serial commands and allows the user to change the switch position, query the position and lockout status and lockout the front-panel controls. The front-panel LED display indicates the switch position and power status.



The switched RJ45 ports are transparent to all data. There are (5) RJ45 female port connectors on the rear panel labeled for ports A, B, C, D and COMMON and  (1) DB9 female Remote connector. All eight signals of the RJ45 interface are switched. For reliability, the Model 7271 maintains its position and signal pathways during a power outage.



The Model 7271 is housed in a slim rack-mount enclosure that measures 19ā€ W x 1.75ā€ H x 8ā€ D (48.3 x 20.3 x 4.4 cm). The switch weighs approximately 4.5 lbs. (2.0 Kg). The attractive anodized black box packaging is EMI/RFI resistant. This switch is available for export. United States government agencies may purchase this switch at a discount via GSA Schedule GS-35F-0286V.



The Model 7271 is shipped complete with a Catalog No. 516682 UL approved 100VAC/240VAC 50/60Hz wall-mount power module that supplies 12 VDC, 500mA to the unit. An optional wide range power module, Catalog No. 517277, is also available. This module is a CE and UL listed table mount unit, 100VAC/240VAC 50/60Hz and is ideal for international applications.



For more information on the Model 7271 visit http://www.electrostandards.com/ProductDetail/?productid=237. Electro Standards manufactures a wide array of high-quality, innovative network products. Electro Standardsā€™ staff of knowledgeable sales engineers is available to assist with product and application questions: 401-943-1164, eslab@electrostandards.com.
